ARCUS SPEC 3D MEDIUM
Medium
ARCUS SPEC 3D MEDIUM is a Spec Grade, 10mm x 10mm small profile linear neon engineered for precision interior and protected exterior detailing. Featuring a 3D twistable design with a 200mm (7.87") bending radius, it delivers CRI 95+ and excellent TM-30 color fidelity with a dot-free output of up to 262 lm/ft (861 lm/m). The integrated Combo System allows for exact made-to-order lengths with 20-40% cost savings, offering a versatile IP54/IP67 solution for high-end coves, millwork, and architectural accents.
• CCT : 2700K, 3000K, 3500K, 4000K
• Ra : ≥ 90
• MacAdam Ellipse(SDCM) : 1 step
• Bending Direction : 3D Bendable (Vertical & Horizontal Bending)
• Mounting : Aluminum Profile, Clips
• Input Voltage : 24V DC
• Color : White (Matte Surface)
• Power : 10W/M (Constant Current)
• IP Rating : IP54/IP67, IK08 with profile
• Dimension : 10mm(W) x 10mm(H)
• Lens : Diffused Silicone
• Operating Temperature : -40℃ to 65℃
• Unit Cut : 41.67mm
• Warranty : 5 Years
• Certification : UL, cUL, TÜV, CE, RoHS, REACH, CB
