ORLUX LARGE
Large
ORLUX LARGE is a robust, architectural-grade neon strip designed for bold linear statements and grand-scale building contours.
Features Field-cut anywhere technology, it ensures a tailored fit for complex architectural geometries, providing seamless, high-output illumination across long runs.
This IP68 rated neon is engineered to withstand demanding outdoor environments, including salt and UV exposure, offering a sleek and powerful direct-view profile for hotels, malls, and large-scale facades where professional-grade reliability and field-adjustability are paramount.
• CCT : 2200K, 2700K, 3000K, 3500K, 4000K, 5300K
• MacAdam Ellipse(SDCM) : ≤3
• Bending Direction : Vertical & Horizontal Bending
• Efficacy: 76LM/W @3000K 3.05W, vertical bending
• Mounting : Aluminum Profile, Clips
• Voltage : 24V DC
• Color : White (Matte Surface)
• Power : 3.05W/M
• IP Rating : IP68, IK10 with profile
• Dimension : 0.63''(W) x 0.67''(H)
• Lens : Diffused Silicone
• Unit cut : Cut anywhere
• Operating Temperature : -40℉ to 149℉ (-40℃ to 65℃)
• Warranty : 5 Years
• Certification : UL, cUL, TÜV, CE, RoHS, REACH, CB
